Sanitary Stainless Steel Food Grade Male Threaded Butterfly Valve with Manual Hand Lever
A sanitary stainless steel ball valve is a valve crafted from stainless steel and subjected to electronic polishing to prevent contamination and the accumulation of media. These valves find application in industries such as food, beverage, and pharmaceuticals, where adherence to sanitary standards is essential.
Working Principles
The sanitary diaphragm valve separates the inner wall of the upper and lower valve body of the diaphragm, so that the valve stem, valve disc and other parts above the diaphragm are not corroded by the medium, the structure of packing seat assures there is no-medium leakage. It not only ensures the purity of the working medium in the pipeline, but also prevents the medium from the working parts in the pipeline. In a diaphragm valve, since the working medium is only in contact with the diaphragm and the valve body, both of which are the food grade FDA approved. The valve can ideally control a variety of working mediums, especially those with chemical corrosion working medium.The diaphragm valve body and gasket with the tight fit to provide the valve body seal and seat seal to ensure the pipeline inside and outside environment completely isolated.
Specification Chart
Max. working pressure | 150 PSI |
Temperature range | -20° ~ +150°C or higher upon request |
Sizes available | 1/2" to 4" |
| End connection | Tri-Clamp, Butt-Weld, Flange, Threaded |
Body material | Stainless Steel 316L |
Ball material | Stainless Steel 316L |
Seal material | FDA Approved EPDM, Silicone, Viton |
Actuator Options | Manual, Pneumatic |
Surface Finish | Ra ≤ 0.8μm (Standard), Ra |
Flow Control | Linear |
Features
● Smooth surface finish and crevice-free construction
● Compact and Lightweight
● Uninterrupted flow path
● Handle or pneumatic actuator options
● No retention design
● Valve stem anti-flying design
