The stainless steel butterfly valve operates by rotating a disc mounted on a central shaft inside the valve body. When the disc rotates parallel to the flow direction, the valve opens, allowing gas or liquid to pass with minimal resistance. When the disc rotates perpendicular to the flow, it presses firmly against the vacuum-rated seat, creating a tight, leak-proof seal suitable for vacuum conditions. The clamp-style body enables easy installation and removal between flanges without disturbing the pipeline. Its design ensures stable operation, precise flow control, and reliable sealing, making it ideal for sanitary, pharmaceutical, and industrial vacuum systems.
Working Pressure | 10 Bar (Max. Pressure is 16bar for but welded connection in small sizes |
Working temperature | -10ºC TO + 120ºC |
Size | 1/2”-12”, DN15-DN300 |
Grade | AISI304 and AISI316L |
FDA approved gaskets in silicone, EPDM, viton, PTFE | |
Connection | Clamp, Weld, Thread,male threaded; female threaded; flange end;union connection |
Surface | Sanitary inside polish (Ra ≤ 0.8 μm) |
Sanitary outside polish (Ra ≤1.6 μm) | |
Standard | ISO, 3A, SMS, RJT, DIN and so on |
Butterfly valve disc and body is made from forging | |
Manual or pneumatic actuated or electric actuated are chosen as per the different applications. | |
Body | Stainless steel AISI316L or AISI 304 (1.4301/1.4404) |
Disc | AISI304 or AISI316L |
Pull-position handle | Stainless Steel Material, Round type or square type |
Multi-position Gripper Handle | ABS gripper handle, SS gripper handle, 2/3/4/12 positions to adjustment, Universal type |
Gasket | EPDM, VITON(FPM), Silicone, different color is available |
Bushing | EPDM or PTFE, other material request |
Nut | Stainless Steel 304 or 316 Material or other request |
Bolt | Stainless Steel 304 or 316 Material or other request |
Constructed from 316L stainless steel, providing excellent corrosion resistance, mechanical strength, and long-term durability for industrial and chemical applications.
Lug-type body allows secure flange installation, enabling easy maintenance and partial pipeline disassembly without affecting the entire system.
Gearbox operation amplifies manual torque, making it easier to operate large-diameter valves with minimal effort.
Visual position indicator provides clear feedback on valve status, helping operators quickly confirm open or closed positions.
The disc and seat design ensures reliable sealing, low leakage, and stable flow control under varying pressure and temperature conditions.
Sanitary Butterfly valve widely use in low and medium viscosity liquid for food and beverage, beer, dairy, pharmaceutical etc with high precision and purity requirements industries.
Working Principles
The stainless steel butterfly valve operates by rotating a disc mounted on a central shaft inside the valve body. When the disc rotates parallel to the flow direction, the valve opens, allowing gas or liquid to pass with minimal resistance. When the disc rotates perpendicular to the flow, it presses firmly against the vacuum-rated seat, creating a tight, leak-proof seal suitable for vacuum conditions. The clamp-style body enables easy installation and removal between flanges without disturbing the pipeline. Its design ensures stable operation, precise flow control, and reliable sealing, making it ideal for sanitary, pharmaceutical, and industrial vacuum systems.
Feature and Specification
Stainless Steel Butterfly Valve Specification Chart
Working Pressure | 10 Bar (Max. Pressure is 16bar for but welded connection in small sizes |
Working temperature | -10ºC TO + 120ºC |
Size | 1/2”-12”, DN15-DN300 |
Grade | AISI304 and AISI316L |
FDA approved gaskets in silicone, EPDM, viton, PTFE | |
Connection | Clamp, Weld, Thread,male threaded; female threaded; flange end;union connection |
Surface | Sanitary inside polish (Ra ≤ 0.8 μm) |
Sanitary outside polish (Ra ≤1.6 μm) | |
Standard | ISO, 3A, SMS, RJT, DIN and so on |
Butterfly valve disc and body is made from forging | |
Manual or pneumatic actuated or electric actuated are chosen as per the different applications. | |
Features
Constructed from 316L stainless steel, providing excellent corrosion resistance, mechanical strength, and long-term durability for industrial and chemical applications.
Lug-type body allows secure flange installation, enabling easy maintenance and partial pipeline disassembly without affecting the entire system.
Gearbox operation amplifies manual torque, making it easier to operate large-diameter valves with minimal effort.
Visual position indicator provides clear feedback on valve status, helping operators quickly confirm open or closed positions.
The disc and seat design ensures reliable sealing, low leakage, and stable flow control under varying pressure and temperature conditions.
Application
Sanitary Butterfly valve widely use in low and medium viscosity liquid for food and beverage, beer, dairy, pharmaceutical etc with high precision and purity requirements industries.
