| Quantity: | |
|---|---|
JN-FT-23 1013
JONENG
7307290000
Stainless Steel Sanitary DIN-D7W AS1528.3 Tri Clamp Equal Tee Tri Clover Fitting
Stainless steel tee is a kind of pipe fittings, connecting with three pipes, changing the direction of the flowing direction. The most popular type is a straight pipe tee. Tees have two outlets from the main flow direction and there is also a third outlet in a 90degree direction way side. The reducing tee is also very common so we can connection the pipeline with different sizes of pipes.
Stainless Steel Elbow Specification Chart
| Material | SS304, SS316L | |
| Size | 1/4''-12'' | |
| Raw material standard | ASTM A-269, A-270, | |
| Connection | Welded end, Triclover end, Male, Female, Flange | |
| Surface | Satin finish, Mirror polish, Vibrating surface, Pickled,EP, Sand Blasting | |
| Standard | 3A/SMS/DIN/ISO2037/ISO1127/AS1528/BS/BPE/IDF | |
| Certificate | ISO, PED,FDA | |
| Products Range | Elbow | 90degree elbow, 45degree elbow, |
| Tee | equal tee, reducing tee | |
| Reducer | concentric reducer, eccentric reducer | |
| Application | Food, Beverage,Phamacy, Dairy, | |
Features
The sizes fit for stainless steel sanitary tubing and piping dimensions
Max. operating pressure rating of 10bar for small sizes
Chemical components carrying in the materials meet the requirement from hygienic and sanitary industry
The elbows with straight end is designed for capacity of orbital welding
Easy for welding free from rust and corrosion Working for high pressure 0-10bar
Feature and Specification
Stainless Steel Elbow Specification Chart
| Material | SS304, SS316L | |
| Size | 1/4''-12'' | |
| Raw material standard | ASTM A-269, A-270, | |
| Connection | Welded end, Triclover end, Male, Female, Flange | |
| Surface | Satin finish, Mirror polish, Vibrating surface, Pickled,EP, Sand Blasting | |
| Standard | 3A/SMS/DIN/ISO2037/ISO1127/AS1528/BS/BPE/IDF | |
| Certificate | ISO, PED,FDA | |
| Products Range | Elbow | 90degree elbow, 45degree elbow, 180degree elbow |
| Tee | equal tee, reducing tee | |
| Reducer | concentric reducer, eccentric reducer | |
| Application | Food, Beverage,Phamacy, Dairy, | |
Features
● The sizes fit for stainless steel sanitary tubing and piping dimensions
● Max. operating pressure rating of 10bar for small sizes
● Chemical components carrying in the materials meet the requirement from hygienic and sanitary industry
● The tees with straight end is designed for capacity of orbital welding
● Easy for welding
● free from rust and corrosion
● Working for high pressure 0-10bar
