Stainless Steel Sanitary API 3 Way Fine Tuning Plug Valve

A plug valve is a type of quarter-turn valve that uses a cylindrical or conical plug to control the flow of fluids through a pipe or pipeline. It is named for its plug-like shape that rotates inside the valve body to open or close the flow passage.
Availability:
Quantity:
  • SMS JN PV 1005

  • JONENG

  • 8481804090

Stainless Steel Sanitary API 3 Way Fine Tuning Plug Valve

The plug valve is excellent sanitary devices with minimal pressure drops, and widely used for viscosity liquid. As the plug valve is sealed by stainless steel.

But can not be used for high pressure. can rotate 360° the plug valve is self-cleaning removing the scaling and adhering media. Plug valve plugs are hard chrome coated, then precision ground and lapped to prevent leaks and provide easier handling.The plug valves are known for their simplicity , reliability and ability to handle high pressure and high temperature applications.


Working Principles

未标题-1

The plug valve has a through hole to open and close the flow direction .The plug valve is a valve with simple structure, quick opening and closing, and relatively small resistance. The plug valve is generally operated by a handle. When the handle of the plug valve is parallel to the valve body, it is in the fully open position, and when the handle of the plug valve is perpendicular to the valve body, it is in the fully closed position, so the plug valve generally cannot be used as a regulating valve.


Stainless Steel Plug Valve Specification Chart

未标题-1

Working temperature

-10°C ~ 150°C

Working Pressure

1bar

Working operate

Manual

Connection end

Weld, Tri-clamped , union, male type

Standard

DIN, 3A, RJT, SMS

Body Material

AISI 304, AISI 316L

Inside surface finish

Ra0.4

Size

DN25-DN100 , 1"-4"

Type

2 way, 3way:T type or L type ball core, 4 way



Features

未标题-1

 Suitable for frequent operation, quick and easy opening and closing.

●    Small fluid resistance.

 Simple structure, relatively small size, light weight, and easy maintenance.

●    Good sealing performance.

●    It is not restricted by the installation direction, and the flow direction of the medium can        be arbitrary.

 No vibration, low noise

 Metal sealing capability to minimize leakage


Application

未标题-1

The plug valves are commonly used in industries like Food, beverage, dairy, pharmacy, chemical or any food processing industries .


螺纹 三通旋塞阀






Working Principles

未标题-1

The plug valve has a through hole to open and close the flow direction .The plug valve is a valve with simple structure, quick opening and closing, and relatively small resistance. The plug valve is generally operated by a handle. When the handle of the plug valve is parallel to the valve body, it is in the fully open position, and when the handle of the plug valve is perpendicular to the valve body, it is in the fully closed position, so the plug valve generally cannot be used as a regulating valve.



Feature and Specification

未标题-1

螺纹 三通旋塞阀

Stainless Steel Plug Valve Specification Chart

未标题-1

Working temperature

-10°C ~ 150°C

Working Pressure

1bar

Working operate

Manual

Connection end

Weld, Tri-clamped , union, male type

Standard

DIN, 3A, RJT, SMS

Body Material

AISI 304, AISI 316L

Inside surface finish

Ra0.4

Size

DN25-DN100 , 1"-4"

Type

2 way, 3way:T type or L type ball core, 4 way



Features

未标题-1

 Suitable for frequent operation, quick and easy opening and closing.

●    Small fluid resistance.


 Simple structure, relatively small size, light weight, and easy maintenance.

●    Good sealing performance.

●    It is not restricted by the installation direction, and the flow direction of the medium can          be arbitrary.

 No vibration, low noise

 Metal sealing capability to minimize leakage




Application

未标题-1

The plug valves are commonly used in industries like Food, beverage, dairy, pharmacy, chemical or any food processing industries .
