STAINLESS STEEL 317 Brand Wireless BPT 13 Thermo Steam Trap
steam trap are available in threaded and flanged types, with various sizes and pressure ratings. They are high-temperature and corrosion-resistant, offer sensitive opening and closing, and provide stable drainage, making them suitable for steam systems.
Working Principles
This steam trap utilizes an inverted tank structure and steam pressure difference to achieve automatic drainage. When condensate enters the valve body, the inverted tank sinks, the valve opens, and the condensate and air are discharged from the pipes. When steam reaches the valve body, the high-speed steam creates pressure below the tank, causing the tank to rise and close the valve, preventing steam leakage. The valve continuously opens and closes in a cycle, achieving efficient drainage. A built-in wireless monitoring module can collect data such as temperature and valve opening/closing status in real time, transmitting this data wirelessly to the control system for operational monitoring and preventative maintenance, improving system safety and energy efficiency.
Stainless Steel Steam Ttap Specification Chart
| Body Material | SS304 / SS316L Stainless Steel |
| Connection Type | Clamp / Threaded / Welded |
| Nominal Size | DN15 – DN50 (1/2" – 2") |
| Design Pressure | PN16 / PN25 / PN40 |
| Working Pressure | 16 – 40 bar |
| Working Temperature | 220 – 400°C |
| Applicable Media | Saturated Steam, Condensate |
| Surface Finish | Ra ≤ 0.8 μm |
| Standards | DIN / SMS / ISO / 3A |
Features
Made from high-grade SS317 stainless steel, offering superior corrosion resistance and long-lasting durability in high-temperature and high-pressure steam systems.
BPT 13 thermodynamic bucket design ensures efficient condensate discharge while minimizing live steam loss under fluctuating loads.
Integrated wireless monitoring module enables real-time tracking of temperature, discharge cycles, and operational status for predictive maintenance.
Compact and robust construction allows easy installation in branch lines or limited-space piping systems.
Simple internal mechanism reduces wear and maintenance frequency, providing reliable, energy-efficient, and continuous operation in industrial steam applications.
Application
This steam trap is widely used in food and beverage, pharmaceutical, bioengineering, chemical, and cleanroom piping systems. For example, it is used in pasteurization equipment, reactor jackets, heat exchangers, and steam tracing pipelines to promptly drain condensate, prevent water hammer, improve heating efficiency, and ensure the stability and safety of the production process.
