JONENG
steam traps are available in balanced pressure type and capsule type, adaptable to different pressure ratings. Specifications cover various connection methods, and materials include SS304 and SS316. They feature quick start-up, good venting, corrosion resistance, energy saving, and stable operation.
This stainless steel steam trap achieves automatic drainage through an inverted tank and float mechanism. When condensate enters the valve body, the inverted tank sinks, opening the valve to discharge condensate and air; as steam arrives, the inverted tank rises to close the valve, preventing steam leakage. A built-in monitoring module records valve opening/closing and temperature status in real time, transmitting signals to help maintenance personnel assess drainage performance. This valve can efficiently drain water from steam tracing lines, heat exchangers, and small industrial pipelines, while also enabling online monitoring and preventative maintenance to ensure stable system operation.
| Body Material | SS304 / SS316L Stainless Steel |
| Connection Type | Clamp / Threaded / Welded |
| Nominal Size | DN15 – DN50 (1/2" – 2") |
| Design Pressure | PN16 / PN25 / PN40 |
| Working Pressure | 16 – 40 bar |
| Working Temperature | 220 – 400°C |
| Applicable Media | Saturated Steam, Condensate |
| Surface Finish | Ra ≤ 0.8 μm |
| Standards | DIN / SMS / ISO / 3A |
Thermodynamic bucket operating principle allows automatic opening and closing based on pressure and velocity differences, ensuring reliable condensate discharge under fluctuating steam loads.
Stainless steel construction provides high strength, corrosion resistance, and long service life in high-temperature and high-pressure steam applications.
Testing design enables easy performance checking and condition assessment during operation, reducing maintenance time and improving system reliability.
Compact FT44 structure suits limited installation space while maintaining efficient drainage and effective steam sealing performance.
Suitable for superheated and saturated steam systems, offering stable operation across wide pressure and temperature ranges
stainless steel steam traps are widely used in the food processing, dairy, pharmaceutical, and chemical industries. For example, in dairy sterilization jacketed piping or chemical reactor steam tracing systems, they are used to continuously discharge condensate and monitor the steam trap's operating status, ensuring uniform steam heating and improving production process stability.
Working Principles
This stainless steel steam trap achieves automatic drainage through an inverted tank and float mechanism. When condensate enters the valve body, the inverted tank sinks, opening the valve to discharge condensate and air; as steam arrives, the inverted tank rises to close the valve, preventing steam leakage. A built-in monitoring module records valve opening/closing and temperature status in real time, transmitting signals to help maintenance personnel assess drainage performance. This valve can efficiently drain water from steam tracing lines, heat exchangers, and small industrial pipelines, while also enabling online monitoring and preventative maintenance to ensure stable system operation.
Feature and Specification
| Body Material | SS304 / SS316L Stainless Steel |
| Connection Type | Clamp / Threaded / Welded |
| Nominal Size | DN15 – DN50 (1/2" – 2") |
| Design Pressure | PN16 / PN25 / PN40 |
| Working Pressure | 16 – 40 bar |
| Working Temperature | 220 – 400°C |
| Applicable Media | Saturated Steam, Condensate |
| Surface Finish | Ra ≤ 0.8 μm |
| Standards | DIN / SMS / ISO / 3A |
Features
Thermodynamic bucket operating principle allows automatic opening and closing based on pressure and velocity differences, ensuring reliable condensate discharge under fluctuating steam loads.
Stainless steel construction provides high strength, corrosion resistance, and long service life in high-temperature and high-pressure steam applications.
Testing design enables easy performance checking and condition assessment during operation, reducing maintenance time and improving system reliability.
Compact FT44 structure suits limited installation space while maintaining efficient drainage and effective steam sealing performance.
Suitable for superheated and saturated steam systems, offering stable operation across wide pressure and temperature ranges
Application
stainless steel steam traps are widely used in the food processing, dairy, pharmaceutical, and chemical industries. For example, in dairy sterilization jacketed piping or chemical reactor steam tracing systems, they are used to continuously discharge condensate and monitor the steam trap's operating status, ensuring uniform steam heating and improving production process stability.
