STAINLESS STEEL TLV Thermostatic FT44 Analyzer Steam Trap
steam traps are available in balanced pressure type and capsule type, adaptable to different pressure ratings. Specifications cover various connection methods, and materials include SS304 and SS316. They feature quick start-up, good venting, corrosion resistance, energy saving, and stable operation.
Working Principles
The stainless steel steam trap achieves automatic drainage through a temperature control element and valve mechanism. When condensate enters the valve body, the temperature control element senses that the temperature is below the steam saturation temperature and contracts, opening the valve to discharge condensate and air from the pipe. When steam or superheated water arrives, the temperature control element expands, pushing the valve closed to prevent steam leakage. The valve cycles between opening and closing, achieving efficient drainage. A built-in analysis module monitors the valve's opening and closing status and temperature in real time, used to evaluate the steam trap's performance and assist in maintenance, improving the safety and energy efficiency of the steam system.
Stainless Steel Steam Ttap Specification Chart
| Body Material | SS304 / SS316L Stainless Steel |
| Connection Type | Clamp / Threaded / Welded |
| Nominal Size | DN15 – DN50 (1/2" – 2") |
| Design Pressure | PN16 / PN25 / PN40 |
| Working Pressure | 16 – 40 bar |
| Working Temperature | 220 – 400°C |
| Applicable Media | Saturated Steam, Condensate |
| Surface Finish | Ra ≤ 0.8 μm |
| Standards | DIN / SMS / ISO / 3A |
Features
Constructed from high-quality stainless steel, providing excellent corrosion resistance and long-term durability in high-temperature and high-pressure steam systems.
Thermostatic element ensures precise condensate discharge while preventing live steam loss, maintaining energy efficiency and stable operation.
Integrated analyzer function monitors temperature and valve operation, enabling real-time performance assessment and predictive maintenance.
Compact FT44 design allows easy installation in limited-space pipelines and branch lines without major modifications.
Simple internal mechanism reduces maintenance requirements while providing reliable, efficient, and continuous condensate removal in industrial applications
Application
The stainless steel steam trap is mainly used in the petrochemical, power, paper, and district heating industries. For example, in the main steam pipelines of power plants or large heat exchange stations, it is used for condensate drainage and operational status testing of high-pressure steam pipelines, helping maintenance personnel to judge the drainage condition in a timely manner and ensuring the safe and stable operation of the system.
